| 模型 | |||
|---|---|---|---|
| Model Number | SEM618D1 | ||
| tets | |||
| Operating Specifications | |||
| Breakout Force | 63 KN | ||
| Max. Drawbar Force | 55 KN | ||
| B-Pin Height | B-Pin Height | ||
| Dump Clearance | 2,691 mm | ||
| Maximum Traction Force | Maximum Traction Force | ||
| Articulated Angle | Articulated Angle | ||
| Main Specifications | |||
| Operating Weight with Standard Bucket | 5,940 kg | ||
| Rated Payload | 1,800 kg | ||
| Bucket Capacity | 0.9-1.0 m³ | 0.9-1.0 m³ | 0.9-1.0 m³ |
| Wheel Base | 2,200 mm | ||
| Overall Dimension | 5,901*2,000*2,822 mm | ||
| Turning Radius over Bucket | test | ||
| Transmission | |||
| Transmission Type | Countershaft, power shift | ||
| Transmission Gears | F2/R2 | ||
| Torque Converter Type | Single stage, 3 elements | ||
| Transmission Model | Transmission Model | ||
| Forward I/Reverse I | 9.8/9.6 | ||
| Forward II/Reverse II | 24/23.6 | ||
| Forward III/Reverse III | Forward III/Reverse III | ||
| Forward IV/Reverse IV | Forward IV/Reverse IV | ||
| Tires | Tires | ||
| Max Speed | Max Speed | ||
| Maker & Type | ZL15 | ||
| Manufacturer and Model | Manufacturer and Model | ||
| Axle (Axle, Tire & Brakes) | |||
| Axle Model | Axle Model | ||
| Main Reducer type | Spiral bevel gear, single stage | ||
| Final Drive Reduction Type | Planetary type, single stage | ||
| Rear- oscillation +/- | ±12 | ||
| Swing Angle | Swing Angle | ||
| Engine | |||
| Engine Model | YT4B4-22 | ||
| Rated Power | 60 kW | ||
| Rated Speed | 2,200 r/min | ||
| Displacement | 4.76 L | ||
| Emission | Emission | ||
| Implement Hydraulic System | |||
| Implement System Type | Open center | ||
| Hydraulic Cycle Time | 7.8 s | ||
| System Pressure Setting | 17 Mpa | ||
| Raise | 4.35 s | ||
| Brake System | |||
| System Type | Shared flow | ||
| Steering Pump Type | Gear pump | ||
| System Pressure Setting | 14 Mpa | ||
| Steering Angle (L/R) | 35±1 ° | ||
| Service Refill Capacity | |||
| Fuel Tank | Fuel Tank | ||
| Engine Lubricating Oil | Engine Lubricating Oil | ||
| Cooling System | Cooling System | ||
| Hydraulic System | Hydraulic System | ||
| Transmission Oil | Transmission Oil | ||
| Axles, Each | Axles, Each | ||
| Tires | |||
| Size | 16/70-20 | ||
| Type | PR | ||
| Layer | 14 | ||
| Textured Type | L-3 | ||
| Optional Features | |||
| High Lift Arm | High Lift Arm | ||
| ROPS & FOPS | ROPS & FOPS | ||
| Three Spool | Three Spool | ||
| GP Bucket | GP Bucket | ||
| Aggregate Bucket | Aggregate Bucket | ||
| Coal Bucket | Coal Bucket | ||
| Rock Bucket | Rock Bucket | ||
| Spade Nose Rock Bucket | Spade Nose Rock Bucket | ||
| Quick Coupler | Quick Coupler | ||
| Hay Fork | Hay Fork | ||
| Sand Tire | Sand Tire | ||
| Radial Tire | Radial Tire | ||
| Oil Bath Filter | Oil Bath Filter | ||
| Transmission Guard | Transmission Guard | ||
